The Results - A Trial Looking at 5 Ways to Prepare Beds for Tree and Shrub Planting - Which one is the best?

Last year we started a trial to discover the best ways to prepare the ground for tree and shrub planting. We trialed five different methods and recorded the performance of each method looking at how long they took to implement and manage, how much they cost and how effective they are.



I'll start the post with why we prepare our ground in advance of planting then we will look at the goal of the trial, overview of the trial garden, overview of the trial itself and finally present the trial results.



Why we prepare our ground in advance of planting


When planting trees and shrubs into grassland or fields previously used for agriculture, I prefer to prepare the area at least 6 months ahead of planting - 12 months is even better. We often prepare the planting zones in early spring for late Autumn planting.  I call this "advance planting preparation" or APP for short.

Advance Planting Preparation - (APP)


What is it ? - It's basically the addition of organic matter into the planting zone 6 - 12 months before planting out to improve the soil conditions for incoming plants. This can be in the form of mulches that suppress existing growth and decompose in situ or in the form of green manures that replace the existing growth and improve the soil.

Why do it ? -

 The benefits for APP include the following :-
  • It's generally acknowledged that early succession plants such as grass and forb prefer bacterial dominated soils whereas trees and shrubs prefer fungal. By preparing soils in advance of planting you can alter soil conditions to that which trees and shrubs are more accustomed to. A great way of shifting the soil ecology from bacterial to fungal is to deep mulch the planting zone with high carbon material such as wood chip (preferably ramial wood chip) or with straw at least 6 - 12 months before planting out. If you live in urban areas ramial wood chip should be very easy to get hold of from your local tree surgeon (often free of charge). In rural areas straw should be available and spoiled straw that has been exposed to the rain during winter is often freely available as it cannot be used for animal bedding.

Wood chip - The smaller diameter the source wood is, and the more green material in the chip, the faster it will decompose. Chip from small diameter source wood is called ramial wood chip and is the best material to use for mulch in APP. Photo credit David Domoney

  • Grass can compete vigorously with trees and shrubs for nutrients and water. The application of heavy mulches reduces or in some cases eliminates the existing vegetation without the need of heavy digging work or the use of tractors and machinery. The vegetation that is suppressed by the mulch decomposes along with the mulch and adds to the fertility of the soil and improves soil structure.
  • You can reduce the expense of time preparing compost or the cost of purchasing it by using fresh manure or other fresh organic matter layered as sheet mulch. Doing so 6 - 12 months ahead of planting allows enough time for the material to decompose in situ to levels that are not harmful to plants.
  • Mulch provides good habitat for a range of invertebrates many of which are beneficial in our garden ecosystems. Slugs and snails will also shelter in the mulch and this often attracts slow worms, toads, frogs and lizards that feed on them under the safety of the cover. Ground beetles and a range of spiders will also make home in the mulch and perhaps the most beneficial of all the soil dwelling organisms, earthworms, will settle and multiply under the mulch slowly bringing the material down into the soil, providing micro drainage, improving structure and creating some of the best plant fertiliser around - vermi-compost.
  • When using green manures you do not find the above benefits, but green manure can improve the soil fertility, relieve compaction, improve the soil structure providing better drainage and water retention, suppress weeds and attract beneficial insects and pest predators.

An excellent green manure - Sainfoin - Onobrychis viciifolia

Things to Consider with APP


  • For large areas you often need to apply large quantities of mulch and manures which means importing from offsite. If you can tap into local waste streams (as mentioned above) this is fine but it some places it can be expensive to purchase and transport these materials.
  • Plants that grow via rhizomes and runners such as brambles and couch grass may grow through or around the sheet mulches and green manure cover. This can be overcome by removing these plants before mulching, or spot weeding as they reappear. If the area is dominated by pernicious weeds it's probably best to take the time to remove them before mulching or sowing.
  • On heavy clay (especially compacted clay) applying mulch to the surface is not very effective as is not easily naturally incorporated into the clay. Furthermore the clay layer can form a barrier or "pan"  that prohibits plant root growth and water percolation.  In such cases it's necessary to incorporate the organic matter into the soil via double digging or deep ploughing the area, adding the organic matter and then rotary tilling. The initial work is intensive but it is a one off investment in time and energy, and following this applying organic matter/mulch to the surface will work (so long as the area is not compacted again).
  • On all compacted soils it's worth breaking the compaction and relieving any hardpan that may be present before adding mulch.
  • In most situations it's necessary to prepare a seed bed when using green manures and this often entails ploughing and tilling the area for large areas or digging over and raking for small areas.
  • Always apply a mulch following periods of heavy rain or water the area well beforehand to ensure the soil is well hydrated. This will activate the microbiology in the soil that play a critical role in nutrient cycling.

There are a number of different ways you can implement APP using organic or inorganic mulches and a diversity of options within those categories, using multiple layers of mulch, combining soil disturbance (forking, turning. tilling) with mulching or concentrating efforts solely to the planting zones or treating whole areas. When using green manures there are a wide range of species to choose from and various mowing/ incorporation strategies you could use. To a large extent the method you may use will depend on what resources you have available and the initial condition of your ground.


The Goal of this Trial



Our goal for this study is to establish APP methods that are inexpensive, time efficient and that will provide the optimal conditions for the incoming plants.

Based on what we have available at our site we decided to try the following 5 methods

1. Inverted Sod and Mulch - A layer of inverted sod placed on existing vegetation and topped with mulch
2. Green Manure - Ploughing - Tilling - Sowing  (Clover - Sainfoin)
3. Fork over and Sheet Mulch - Forking over applying card layer topping with fresh manure and covering with mulch
4. Sheet Mulch - Applying card layer to exisiting vegetation topping with fresh manure and covering with straw mulch
5. Straw Mulch - Applying a layer of straw mulch to existing vegetation

Before we go on to profile each of these methods, here's an overview of the garden we are working on and a description of the trial.

Overview of the Trial Garden


Location: Bulgaria, Shipka
Area: 350 m2
​Climate: Temperate
K√∂ppen Climate Classification - Dfc borderline Cfb
USDA Hardiness Zone: 5b
Latitude: 42°
Elevation: 571 m
Average Annual Rainfall: 598 mm
Prevailing Wind: NW & NE
Garden Name: Ataraxia- Perennial Polyculture Trial Beds


Here is the plot before development began and after we installed the beds

The trail site before and after. The mini digger in the background is digging a pond on the plot and has nothing to do with this trial.


In April 2017 we began the development of our trial garden - Ataraxia. In this garden we grow a range of fruit trees and shrubs mixed with habitat for wildlife and support species to reduce pests and disease, and we are attempting to support the crop production by growing support plants that provide nutrition to the crops such as nitrogen fixing plantsmineral repositors and biomass plants(See here for planting schemes)



We combine the plants and habitat together in polycultures and experiment with these polycultures in order to discover best practices that can produce nutritious affordable food while enhancing biodiversity.


A Shameless Plug of our new Online Store




http://www.thepolycultureproject.com/store/c2/Grow_your_Own_Polyculture_.html
Grow your own permaculture polycultures -  seed, tubers, bulbs and cuttings


Overview of The Trial


The trial plot is 337.5 m2 and is composed of 6 beds each, 1.5 m wide and 25 m long. The beds are labeled A - F. Beds A, C and E are designated for biomass (support) plants and Beds B, D and F are designated to perennial polycultures (for the species list of these beds see here).

Perennial Polyculture Trial Beds

The biomass beds A, C and E are prepared without the addition of manures as the biomass plants we are using grow well in soils of low - moderate fertility and as the purpose of growing these plants is to provide fertility to the productive plants in the adjacent beds it does not make sense to use fertility additives to grow these plants. The perennial polyculture beds will include 3 layers of productive plants and a bulb layer so we want to boost fertility and improve soil structure for the initial planting hence each method includes the fertility additive. In the case of Bed B we used green manure and for beds D and F we added manure.  The table and diagram below indicates the APP method used for each bed along with the planting culture.


Advance Planting Preparation Trials
6 Beds - 25m long x 1.5m wide
BedAdvance Planting Preparation (APP) MethodsPlanting Schemes
Bed A1. Inverted Sod and Mulch - (Soil-Straw)Biomass Bed 1 - Nitrogen Fixing Trees + Control
Bed B2. Green Manure - (Plough - Till-Sow)Perennial Polyculture 1
Bed C5. Straw Mulch (Straw)Biomass Bed 2 - Herbaceous Perennials
Bed D3. Fork over and Sheet Mulch - (Card-Manure-Straw)Perennial Polyculture 2
Bed E5. Straw Mulch (Straw)Biomass Bed 3 - Nitrogen Fixing Trees
Bed F4. Sheet Mulch - (Card-Manure-Straw)Perennial Polyculture 3







The pathways between the beds are 50cm wide and the perimeter pathway around the trial beds is 1m wide. The width of the pathways was determined by the width of the lawn mower we use. We keep the existing vegetation on the pathways and mow them regularly throughout the growing season (April - Sep). Mowing the vegetated pathways provides an excellent source of biomass with each 27m long pathway producing approximately 30L of trimmings per mow which may be as often as once per week if we have had rain. The trimmings are deposited around the base of the fruit trees and shrubs in the perennial polyculture beds (as long as it's not full of ripe seed). Root biomass from the roots is also shed following a cut. Once decomposed this root biomass provides a great source of fertility in sub and top soil for the surrounding plants.  Furthermore, the vegetated pathways also provide habitat, notably forage for beneficial insects, when plants flower during the months we are not cutting, namely late autumn - early spring. Another advantage of our vegetated pathways is that they provide comfortable access during very wet periods and do not become muddy.

Bed and pathway dimensions

Sophie mowing the pathways in early spring

The perennial polyculture trial beds -  6 beds - 1.5m wide and 25m long with 50 cm internal pathways and 1m wide periphery pathways. A is on the far right.

So let's look at the 5 different methods we tested to prepare the ground for planting our perennial polycultures.

Our five methods for advance planting preparations


1. Inverted Sod and Mulch - (Soil - Straw)
2. Green Manure - (Plough - Till - Sow White Clover - Sainfoin and Marigolds)
3. Dig over and Sheet Mulch - (Card - Manure - Straw)
4. Sheet Mulch - (Card - Manure - Straw)
5. Straw Mulch (Straw)

All of these methods are intended to be applied 6 - 12 months in advance of planting and are best implemented when the soil is moist, for example, following heavy rains when the soil profile is thoroughly soaked but has had enough time to drain and is not water logged.

1. Inverted Sod - Bed A


Method one entails slashing the existing vegetation to ground level and applying it to the surface of the planting area. A layer of inverted sod is then applied to cover the surface of the bed. In some cases you may wish to dig out the top soil from the pathways and this can be inverted on to the bed area. In our case we wished to leave the pathways grassed and used top soil removed from a pond excavation on site. Following the top soil a layer of straw mulch was applied approx 10-20 cm deep.


Inverted Sod applied to surface. This is followed by a layer of straw


2. Green Manure - Bed B


Method two removes the existing vegetation and replaces it with plants that can improve the soil for the incoming plants. For example, on sites with low fertility soils, nitrogen fixing green manures are great way to lift Nitrogen (N) to appropriate levels. The green manures can also add significant quantities of organic matter to the soil, improving structure and drainage and serving the needs of beneficial insects.

To boost the organic matter content of the soils, the green manure should be cut at regular intervals and plowed into the soil or covered with a straw mulch before planting occurs. In such cases the green manure used should be a fast growing annual cover.  An alternative is to sow a perennial cover, cut back at regular intervals (once established) and plant the crops directly into the living mulch.

We sowed the following seeds onto the prepared bed on the 18th May.

Trifolium repens - White Clover 200 g - Perennial
Tagetes patula 100 g - Annual
Onobrychis viciifolia - Sainfoin 100 g - Perennial

During dry periods irrigation may be necessary,

To prepare for sowing we ploughed and rotary tilled the area to provide a good seed bed.


1.5 m wide plough followed by rotary till prepares the bed for green manure


We then hand sowed the seed onto the surface before a rainy period was forecast.

Hand sowing the cover crop onto the surface


The use of cover crops to prepare beds for perennial polycultures is something we'll be experimenting with more in the future.


3. Fork over and Sheet Mulch


Method 3 entails slashing the existing vegetation to ground level, forking over the surface of the beds and then placing a card layer to cover the soil surface and a layer of manure on top of the card. We used approx 30L of manure per m2 and finally topped this with a 10-20cm  layer of straw.

Forking over the bed, placing a layer of card and cloth, adding 30 L of manure and covering with 15-20 cm deep layer of straw.

4. Sheet Mulch- Cardboard layer, manure layer , straw layer


Method 4 is the same as above but without forking over the beds

5. Straw Bales


Method 5 is quite simply slashing the existing vegetation to ground level and applying a 20cm layer of straw to the surface. Another way is to place a straw bale on the location where each tree will be planted and this works really well if you are only planting a tree layer. However for these beds we intend to plant out 4 layers; trees, shrubs, perennial vegetables and bulbs and we had the bales available so it made more sense to mulch the entire area.


The bales spaced out evenly before cutting the strings and spreading the straw out


What and Why we Record


We recorded the input of each method looking at how long they took to implement and manage, how much they cost and we took soil analysis to establish how effective each method is.

Our goal for this study is to establish APP methods that are inexpensive, time efficient and that will provide the optimal conditions for the incoming plants.


Record of Inputs - The inputs we record are time to implement - time to manage and the cost of each method.  We are looking for the method that requires the smallest amount of resources for the greatest benefit.
  • Time to Implement - How long it takes to implement each method
  • Time to Manage - How long it takes to manage each method up to the point of planting - ie mowing, weeding, irrigation.
  • Materials Needed - Materials required for each method
  • Cost of Each Method - How much each method costs to implement

Soil Analysis  - We aim to provide the optimal conditions for the incoming plants and measure the effectiveness of each method is by carrying out a mineral and physical soil analysis, comparing these  to base samples.

  • Soil  Mineral Analysis - Annual samples are taken and sent NAAS of the Ministry of Agriculture and Food. These samples are compared to base sample taken before work began in Autumn 2016
  • Soil Physical Analysis -  Annual soil tests are carried out on each bed. The analysis includes a series of 9 simple tests that are designed to provide an indication of soil health based on observable physical properties of the soil. You can find instructions on how to carry out this test here. These tests are compared to a base sample we took before the trail began. Higher marks on the test indicate improved soil conditions.

The Results-  Record of Inputs


Time to Implement


Here are the total number of minutes we spent on each APP method.


Time to Implement
Bed Advance Planting Preparation (APP) MethodsTotal Time Notes
Bed A1. Inverted Sod
Mulch - (Soil-Straw)
75 mins
Times do not include bringing materials to the site
All times excluding the green manure trial are based on 2 people carrying out the task
Bed B 2. Green Manure - (Plough - Till-Sow)60 mins
Bed C5. Straw Mulch (Straw)30 mins
Bed D3. Fork over and Sheet Mulch - (Card-Manure-Straw)140 mins
Bed E5. Straw Mulch (Straw)30 mins
Bed F4. Sheet Mulch - (Card-Manure-Straw)95 mins


Time to Manage


The management time is recorded from after establishing the beds until the point that we plant out. Management tasks include weeding the mulched beds and in the case of the green manure trial cutting back the vegetation in the following spring after planting. The weeding is carried out to check the most vigorous plants that grow through the mulch so there will be little competition for our incoming productive plants. The weeds are collected and composted and applied back the beds later.



Time to Manage (12 months before planting)
Bed Advance Planting Preparation (APP) MethodsTotal Time Management Notes
Bed A1. Inverted Sod and Mulch - (Soil-Straw)296 minutes Weeding
Different people carried out the weeding tasks at different paces. This data is not very useful
Bed B 2. Green Manure - (Plough - Till-Sow)110 minutes Cutting back
Bed C5. Straw Mulch (Straw)260 minutes Weeding
Bed D3. Fork over and Sheet Mulch - (Card-Manure-Straw)298 minutes Weeding
Bed E5. Straw Mulch (Straw)165 minutes Weeding
Bed F4. Sheet Mulch - (Card-Manure-Straw)167.5 minutes Weeding

Here you can see the weed growth in the various beds 3 months after we established the beds.





Cost Analysis


Here are the costs of each of the methods


Cost of each Method
Bed Advance Planting Preparation (APP) MethodsMaterials Costs Notes
Bed A1. Inverted Sod and Mulch - (Soil-Straw)15 Straw Bales
1.875m3 of sod of top soil
15 BGN
Top soil/sods 0BGN
1 Bale costs 1BGN
750L Manure costs 25 BGN
Cardboard costs 0 BGN
Hiring tractor and driver 50BGN
Labour is not included
Bed B 2. Green Manure - (Plough - Till-Sow)Trifolium repens - White Clover 200 g - Perennial
Tagetes patula 100 g - Annual
Onobrychis viciifolia - Sainfoin 100 g - Perennial
Mouldboard Plough Rotary Till - Hire
55 BGN
Bed C5. Straw Mulch (Straw)25 Straw Bales 25 BGN
Bed D3. Fork over and Sheet Mulch - (Card-Manure-Straw)15 Straw Bales
750 L Manure
30m2 Card
40 BGN
Bed E5. Straw Mulch (Straw)25 Straw Bales 25BGN
Bed F4. Sheet Mulch - (Card-Manure-Straw)15 Straw Bales
750L Manure
30m2 Card
40 BGN


The Results - Soil Analysis


Soil Mineral Analysis


Here are the results of the soil mineral analysis including the base test and a test for each of the beds.

Soil Analysis - Ataraxia
Results of Base Analysis taken in Autumn 2016
Nitrogen mg/kgPhosphorous - Potassium mg/100g
November 2016pH (KCI)N03N NH4NP205K20
5.746.333.7710.317
The nutrient content of the soil is adequate if the following quantities are contained in 100 g of soil:
P2O5
11–25 mg/100g
phosphate
K2O
11–32 mg/100g
potassium
Results of Analysis taken Sping 2018
Bed A - APP 1. Inverted Sod and Mulch
Nitrogen mg/kgPhosphorous - Potassium mg/100g
March 2018pH (KCI)N03N NH4NP205K20
6.172.189.6614.232.6
Bed B - APP 2. Green Manure
Nitrogen mg/kgPhosphorous - Potassium mg/100g
March 2018pH (KCI)N03N NH4NP205K20
6.5446.75.913.220.2
Bed C and E - APP 5. Straw Mulch
Nitrogen mg/kgPhosphorous - Potassium mg/100g
March 2018pH (KCI)N03N NH4NP205K20
5.957.957.3410.836.3
Bed D - APP 3. Dig over and Sheet Mulch
Nitrogen mg/kgPhosphorous - Potassium mg/100g
March 2018pH (KCI)N03N NH4NP205K20
6.8334.66.8268.9120
Bed F - APP 4. Sheet Mulch
Nitrogen mg/kgPhosphorous - Potassium mg/100g
March 2018pH (KCI)N03N NH4NP205K20
6.5628.94.8839.4107

Soil Physical Analysis


Here are the results of the soil mineral analysis including the base test and a test for each of the beds.



Soil Physical Analysis - Ataraxia
2017 - Base Test
TESTRESULTTEST SCORES 1 - 9
POOR 1 --------- 2 --------- 3FAIR 4 --------- 5 -------- 6GOOD 7 ---------- 8 --------- 9Av
1.GROUND COVERLess than 50% ground cover [ground plants or mulch50% to 75% ground cover [ground plant or mulch]more than 75% ground cover [ground plant or mulch]8
2.PENETROMETERWire probe will not penetrateWire probe penetrates with difficulty to less than 20 cmWire probe easily penetrates to 20 zm1
3.INFILTRATIONMore than 7 minutes3 to 7 minutesLess than 3 minutes2
4. DIVERSITY OF MACROLIFEFewer than two types of soil animalsTwo to five types of soil animalsMore than five types of soil animals7
5. ROOT DEVELOPMENTFew fine roots only found near the surfaceSome fine roots mostly near the surfaceMany fine roots throughout5
6. SOIL STRUCTUREMostly in clods or with a surface crust, few crumbsSome clods but also many 10mm crumbsFriable, readily breaks into 10mm crumbs8
7. AGGREGATE STABILITYAggregate broke apart in less than one minuteAggregate remained intact after one minuteAggregate remained intact after swirling
10cm depth9
20 cm depth4
8. EARTHWORMS1
45
2018 - APP Trials
Bed A - APP 1. Inverted Sod and Mulch - (Soil-Straw)
TESTRESULTTEST SCORES 1 - 9
POOR 1 --------- 2 --------- 3FAIR 4 --------- 5 -------- 6GOOD 7 ---------- 8 --------- 912Av
1.GROUND COVERLess than 50% ground cover [ground plants or mulch50% to 75% ground cover [ground plant or mulch]more than 75% ground cover [ground plant or mulch]999
2.PENETROMETERWire probe will not penetrateWire probe penetrates with difficulty to less than 20 cmWire probe easily penetrates to 20 zm565.5
3.INFILTRATIONMore than 7 minutes3 to 7 minutesLess than 3 minutes898.5
4. DIVERSITY OF MACROLIFEFewer than two types of soil animalsTwo to five types of soil animalsMore than five types of soil animals111
5. ROOT DEVELOPMENTFew fine roots only found near the surfaceSome fine roots mostly near the surfaceMany fine roots throughout666
6. SOIL STRUCTUREMostly in clods or with a surface crust, few crumbsSome clods but also many 10mm crumbsFriable, readily breaks into 10mm crumbs999
7. AGGREGATE STABILITYAggregate broke apart in less than one minuteAggregate remained intact after one minuteAggregate remained intact after swirling
10cm depth877.5
20 cm depth777
8. EARTHWORMS465
58.5
Bed B - APP 2. Green Manure - (Plough - Till-Sow)
TESTRESULTTEST SCORES 1 - 9
POOR 1 --------- 2 --------- 3FAIR 4 --------- 5 -------- 6GOOD 7 ---------- 8 --------- 912Av
1.GROUND COVERLess than 50% ground cover [ground plants or mulch50% to 75% ground cover [ground plant or mulch]more than 75% ground cover [ground plant or mulch]999
2.PENETROMETERWire probe will not penetrateWire probe penetrates with difficulty to less than 20 cmWire probe easily penetrates to 20 zm555
3.INFILTRATIONMore than 7 minutes3 to 7 minutesLess than 3 minutes475.5
4. DIVERSITY OF MACROLIFEFewer than two types of soil animalsTwo to five types of soil animalsMore than five types of soil animals232.5
5. ROOT DEVELOPMENTFew fine roots only found near the surfaceSome fine roots mostly near the surfaceMany fine roots throughout798
6. SOIL STRUCTUREMostly in clods or with a surface crust, few crumbsSome clods but also many 10mm crumbsFriable, readily breaks into 10mm crumbs988.5
7. AGGREGATE STABILITYAggregate broke apart in less than one minuteAggregate remained intact after one minuteAggregate remained intact after swirling
10cm depth946.5
20 cm depth624
8. EARTHWORMS163.5
52.5
Bed C and E - APP 5. Straw Mulch (Straw)
TESTRESULTTEST SCORES 1 - 9
POOR 1 --------- 2 --------- 3FAIR 4 --------- 5 -------- 6GOOD 7 ---------- 8 --------- 912Av
1.GROUND COVERLess than 50% ground cover [ground plants or mulch50% to 75% ground cover [ground plant or mulch]more than 75% ground cover [ground plant or mulch]999
2.PENETROMETERWire probe will not penetrateWire probe penetrates with difficulty to less than 20 cmWire probe easily penetrates to 20 zm555
3.INFILTRATIONMore than 7 minutes3 to 7 minutesLess than 3 minutes555
4. DIVERSITY OF MACROLIFEFewer than two types of soil animalsTwo to five types of soil animalsMore than five types of soil animals111
5. ROOT DEVELOPMENTFew fine roots only found near the surfaceSome fine roots mostly near the surfaceMany fine roots throughout354
6. SOIL STRUCTUREMostly in clods or with a surface crust, few crumbsSome clods but also many 10mm crumbsFriable, readily breaks into 10mm crumbs777
7. AGGREGATE STABILITYAggregate broke apart in less than one minuteAggregate remained intact after one minuteAggregate remained intact after swirling
10cm depth766.5
20 cm depth846
8. EARTHWORMS898.5
52
Bed D - APP 3. Dig over and Sheet Mulch - (Card-Manure-Straw)
TESTRESULTTEST SCORES 1 - 9
POOR 1 --------- 2 --------- 3FAIR 4 --------- 5 -------- 6GOOD 7 ---------- 8 --------- 912Av
1.GROUND COVERLess than 50% ground cover [ground plants or mulch50% to 75% ground cover [ground plant or mulch]more than 75% ground cover [ground plant or mulch]999
2.PENETROMETERWire probe will not penetrateWire probe penetrates with difficulty to less than 20 cmWire probe easily penetrates to 20 zm444
3.INFILTRATIONMore than 7 minutes3 to 7 minutesLess than 3 minutes999
4. DIVERSITY OF MACROLIFEFewer than two types of soil animalsTwo to five types of soil animalsMore than five types of soil animals232.5
5. ROOT DEVELOPMENTFew fine roots only found near the surfaceSome fine roots mostly near the surfaceMany fine roots throughout354
6. SOIL STRUCTUREMostly in clods or with a surface crust, few crumbsSome clods but also many 10mm crumbsFriable, readily breaks into 10mm crumbs586.5
7. AGGREGATE STABILITYAggregate broke apart in less than one minuteAggregate remained intact after one minuteAggregate remained intact after swirling
10cm depth666
20 cm depth576
8. EARTHWORMS798
55
Bed F - APP 4. Sheet Mulch - (Card-Manure-Straw)
TESTRESULTTEST SCORES 1 - 9
POOR 1 --------- 2 --------- 3FAIR 4 --------- 5 -------- 6GOOD 7 ---------- 8 --------- 912Av
1.GROUND COVERLess than 50% ground cover [ground plants or mulch50% to 75% ground cover [ground plant or mulch]more than 75% ground cover [ground plant or mulch]999
2.PENETROMETERWire probe will not penetrateWire probe penetrates with difficulty to less than 20 cmWire probe easily penetrates to 20 zm454.5
3.INFILTRATIONMore than 7 minutes3 to 7 minutesLess than 3 minutes888
4. DIVERSITY OF MACROLIFEFewer than two types of soil animalsTwo to five types of soil animalsMore than five types of soil animals423
5. ROOT DEVELOPMENTFew fine roots only found near the surfaceSome fine roots mostly near the surfaceMany fine roots throughout666
6. SOIL STRUCTUREMostly in clods or with a surface crust, few crumbsSome clods but also many 10mm crumbsFriable, readily breaks into 10mm crumbs898.5
7. AGGREGATE STABILITYAggregate broke apart in less than one minuteAggregate remained intact after one minuteAggregate remained intact after swirling
10cm depth999
20 cm depth496.5
8. EARTHWORMS988.5
63


Summary of Results



Let's look at which method performed best and worst in each of the categories we tested.

Time to Implement - No surprise in that APP method 5. Straw Mulch was the fastest to implement and that APP method 3. Fork over and Sheet Mulch took the longest.

Time to Manage - APP method 2. Green Manure  took the least amount of time to manage and APP method 3. Fork over and Sheet Mulch - took the longest amount of time to manage. Although it's safe to say that  APP method 2. Green Manure does in fact take the least amount of time to manage for the other beds the data is not useful as the weeding was carried out by different people at a different pace. If we did this again it would be better to recording individual times and take an average. It is worth noting however that adding a layer of card below the straw mulch is as effective at suppressing weeds as doubling up on straw without a card layer.

Personally I prefer to allow weeds to establish and use them as a resoure. All the time weeds are growing in your beds they are transforming sunlight, water, oxygen and carbon dioxide into biomass, biomass that can be used to feed the soil and create fertility. I consider the weeds support plants and only feel it necessary to remove them when they may cause competitive stress to the productive plants. The point of weeding in this trial was to compare how well each method checked weed growth and it seems very clear to me that none of the methods are suitable. The time it takes to weed the beds is very high making this restrictive for large scale operations. In order to heavily reduce weed growth an alternative option is to use heavy duty landscapers mat which allows water and gasses to enter the soil whilst restricting weed growth (plant seed that blows in with the wind will still establish). I'd saying growing weeds for support and devising better tools for chop and drop is the way forward for perennial polyculture.

Another thing to mention here is that in the sheet mulched beds we actually introduced some pernicious weeds with the manure, specifically Cynodon dactylon - Bermuda Grass which spreads to form a mat and is difficult to remove.  Composting the manure in a hot compost pile can kill these weed seeds but is very time intensive and perhaps placing the card over the manure rather than under the manure may slow them but i'm sure the seeds will germinate after the card has decomposed. We're  trying out a method where we cover the beds with greenhouse plastic during a hot summers week.We'll see whether this will destroy the roots of the plants too.

Cost of Each Method - The least expensive was APP method 1. Inverted Sod and Mulch this is the case as long as you have the top soil on site. The most expensive was APP method 2. Green Manure.

Based on the results of the soil analysis we can get an idea which method provided the optimal conditions for the incoming plants.

Soil  Mineral Analysis The APP methods used for the biomass beds A,C and E are not intended to provide fertility. This comparative test is between the methods used on beds B, D and F.

APP method  2. Green Manure proved the least fertile method however it will be interesting to take these results again next year with time for nitrogen fixing green manure plants to take effect.  No surprise that APP methods 3. Fork over and Sheet Mulch and 4. Sheet Mulch - (Card-Manure-Straw) provided the highest fertility what with the manure inputs and it's great to see how these methods provide optimal pH levels when compared to the base sample.

Soil Physical Analysis -  All of the methods improved upon the base test. The most effective method was APP 4. Sheet Mulch the least effective was APP 5. Straw Mulch just slightly worse than APP 2. Green Manure. Our practical experience when planting out the beds in the Spring of this year backs up the results of the soil tests. We found digging the planting holes easiest in Bed F - APP 4. Sheet Mulch and most difficult in Bed B - APP 2. Green Manure.



Soil Physical Analysis - Ataraxia
Rank Sample Score
1Bed F - APP 4. Sheet Mulch 63
2Bed A - APP 1. Inverted Sod and Mulch 58.5
3Bed D - APP 3. Dig over and Sheet Mulch 55
4Bed B - APP 2. Green Manure52.5
5Bed C and E - APP 5. Straw Mulch 52
Base Test 45

This was the biggest surprise of the trial for me as I was expecting to find that the APP 2 Green Manure - (Plough - Till-Sow) trial would render the beds in best shape for planting what with the ploughing and tilling loosening up the soil profile. I was pleasantly surprised to see that we can achieve better results without the heavy equipment and soil disturbance.

We're looking forward to try out a different set of methods in a new trial garden next year. I'd like to experiment with using plastic mulches combined with green manures, deep spot mulching and rough mulching.

I hope you have found this information useful and if so please consider supporting our project so we can improve our studies and keep bringing you information. You can support our project in the following ways.

  • Purchases seeds or plants from our nursery. You can find a variety of plants or seeds from our BioNursery here and start building your own  productive bio-diverse gardens.
  • Join us on one of our upcoming Courses and enjoy an educational adventure in rural Bulgaria where you'll be learning how to create regenerative landscapes and polycultures producing food and other resources while enhancing biodiversity.
  • You can also donate directly to our Polyculture ProjectSee here for the interesting rewards you will receive for your donation.



We also accept donations in ETH, BTC and DOGE



I'd like to say a huge thank you to the team of volunteers that have helped us with this study and that make it possible for us to carry out our experiments and research. It was a pleasure to work together with you :)

Thank you Fergus Webster, Gabriele Landi, Chris Mallorie, Ute Villavicencio, Charlie Morton, Chris Kirby-Lambert, Simon, Kartini, Karl and Marlene, William Kunkle, Rosa Van Giessen, Peter, Stephen and Sonny Alfrey, Angela Rice, Malcolm Cannon, Victoria Bezhitashvili, Elise Bijl, Alex Camilleri, Daniel Stradner, Emilce Nonquepan



If you would like to create a forest garden and would like some practical hands on experience take a look at our course coming up this Autumn. We'll be covering site surveying, landscape design software, installing access, beds, irrigation channels, planting tree, shrub, herb and ground layers and making a small wildlife pond. All in 3 days! And plenty of follow up material to take away with you to digest slowly.
We offer a range of plants and seeds for permaculture and forest gardens from our plant nursery including a range of fruit and nut cultivars. Delivery to all over Europe available from Nov - March


4 comments:

  1. An amazing piece of research from the Balkan Project. keep up the good work. I've been trying with mixed success and quite a bit of failure to claim back 20 years of agricultural usage and 10 years of dereliction on an acre plot. This piece of research has probably save me a year of experimentation

    ReplyDelete
    Replies
    1. Hi Corinne

      Thank you and good luck with your project :)

      Delete
  2. Very nice and useful.
    I am happy to talk to you about the root systems that after most suitable for young trees. Frank Buddingh' MSc. Arboricultual Consultant.

    ReplyDelete
